Specifications:

• Working voltage:DC12V

• Circuit load capacity: maximum current per output 5A, the bus currents up 9A

• Output Range: The first channel 20% -100%, or 40% -100% (TFL = ON)

• The second channel and the third channel 10% -100%
  (Note: Above range only for PWM range, the actual control effect will vary depending on the fan.)

• Temperature probe parameters: 50K B = 3950

• Thermostat temperature zone error: error depending on the temperature probe, generally 3-5%

• Stall alarm minimum speed: 700-800 rpm
