SGP41 VOC and NOX sensors (for intelligent air handling equipment)
SGP4 is a VOC (volatile organic compounds) and NOx (nitrogen oxides) sensor designed as a digital intelligent switch and regulating unit that can be applied to air treatment equipment such as purifiers. Powerful gas index algorithm, the two sensor signals are processed by the algorithm and can directly trigger the air processing equipment without user involvement. Therefore, this sensor solution is highly suitable for continuous monitoring of VOC and NOx (including potentially harmful environments that humans cannot detect). In addition, the air handling equipment based on SGP41 signal has automatic control function. Once VOC and/or NOx issues are addressed, the equipment will shut down, which helps to save energy. The multi pixel sensing element of SGP41 has unparalleled reliability, long-term stability, and low drift in response to polluted gases in real-life environments.

Parameters:

1. Power supply voltage: DC3.3v-5v

2. Communication interface: I2C

3. Power consumption: 40mA

4. Product size: 13mm * 10.5mm

Features:

1. The product is compact and easy to carry

2. Low consumption, power supply compatible with 3.3V-5V

3. Digital output signal I2C interface

4. MOx based gas sensor for air quality applications

5. Wide range of use: can be applied to air handling equipment (such as purifiers), air exchange devices, kitchen range hoods, and on-demand controlled ventilation systems
