Features:

• Chip board ENC28J60/SS.

• The board 25MHZ crystal.

• The network interface board HR911105A.

• 3.3 V power supply pin.

• Size: 5cm x 2cm x 1.5cm /1.92''x0.72''


Specifications:

• Ethernet LAN Module for Arduino/AVR/LPC/STM3

• ENC28J60 Ethernet chips

• Can be easily mounted with the MCU

• Network Interface: HR911105A

• Supply Voltage: 3.3 V (5V Tolerant DIO)

• 25Mhz crystal oscillator

• Size (L x W x H): Approx. 2.3 x 1.3 x 0.7 inch / 58 x 34 x 17 mm

PINOUT:

• 1    CLK OUT

• 2    INT

• 3    WOL

• 4    SO

• 5    SI

• 6    SCK

• 7    CS

• 8    RES

• 9    +3.3V

• 10    GND
