12V DC Power Distribution 9-way PCB board

$12.99

Shipping calculated at checkout.

Quantity

The 12V AC-DC Switching Power Supply Board converts 85-265V AC mains input to a regulated 12V DC output, making it suitable for electronic equipment, automation systems, LED projects, access control, security systems, robotics, and DIY electronics.

Designed as a compact open-frame PCB power supply, it offers up to 90% specified efficiency, low output ripple, stable voltage regulation, and durable screw terminal connections for easy integration into electronic equipment.

Key Features

  • Converts 85-265V AC to 12V DC
  • Wide 50-60Hz AC input range
  • Regulated 12V DC output
  • Up to 90% specified efficiency
  • Output ripple and noise: approximately 110mV P-P
  • Output voltage accuracy: ±1.0%
  • Voltage regulation: ±0.5%
  • Load regulation: ±0.5%
  • Full-bridge switching topology
  • Pulse frequency / width modulation
  • Durable PCB construction
  • Corrosion-resistant terminal blocks
  • Operating temperature from -20°C to +60°C
  • CE specified
  • Suitable for electronics and industrial integration

Technical Specifications

  • Product Type: AC-DC Switching Power Supply Board
  • Input Voltage: 85-265V AC
  • Input Frequency: 50-60Hz
  • Output Voltage: 12V DC
  • Efficiency: Up to 90%
  • Output Ripple & Noise: Approx. 110mV P-P
  • Output Voltage Accuracy: ±1.0%
  • Voltage Regulation: ±0.5%
  • Load Regulation: ±0.5%
  • Topology: Full-Bridge
  • Modulation: Pulse Frequency / Width Modulation
  • Operating Temperature: -20°C to +60°C
  • Connection: Screw Terminal Blocks
  • Construction: Open-Frame PCB
  • Certification: CE specified

Stable 12V Power Output

This switching power supply module provides a stable 12V DC output from a wide 85-265V AC input range. Its voltage and load regulation help maintain consistent output as operating conditions change.

Typical Applications

  • Arduino and electronic projects
  • Robotics
  • Automation systems
  • LED lighting and displays
  • Access control systems
  • CCTV and security equipment
  • Electronic controllers
  • Industrial control equipment
  • Embedded systems
  • DIY electronics
  • Monitoring equipment
  • Electronic instruments

Important Output Rating Note

The supplied specifications state a 12V DC output, but the maximum output current and total wattage have not been provided. The maximum current rating should be confirmed before connecting the power supply to a load.

Safety Warning

This is an open-frame mains-powered AC-DC power supply and contains potentially dangerous high voltages. Installation should be performed by a qualified person and the board should be mounted inside a suitable insulated enclosure. Disconnect AC power before installation or wiring and do not touch the PCB while energized.

Package Includes

  • 1 × 12V AC-DC Switching Power Supply Board

Enclosure, AC wiring, fuse, connectors, and other accessories are not included.
