| Features | Specification |
|---|---|
| Nominal Diameter (Size) | DN32 (1 ¼ inch) |
| Flow Range | Standard: 1.5 to 15 m³/h (cubic meters per hour) or 25 to 250 L/min (liters per minute) |
| Accuracy | Standard: ±1.0% of reading. Optional: ±0.5%R or ±0.2%R |
| Repeatability | ±0.1% to ±0.2% |
| Body Material | Stainless Steel SS304 (Standard) or SS316L (Optional) |
| Impeller/Rotor Material | 2Cr13 Stainless Steel (Standard) |
| Medium Temperature | -20°C to +80°C (Standard), customizable up to +120°C or +180°C |
| Max Pressure Rating | Typically 6.3 MPa (approx. 63 Bar/900 PSI) for threaded connections or 1.6 MPa (16 Bar) for flanged connections |
| Power Supply | Standard: 12-24V DC. Optional: 3.6V Lithium Battery for local display |
| Output Signal | Pulse Output (Standard). Optional: 4-20mA analog signal, RS485 (MODBUS) communication |
| Connection Type | Male/Female Threaded (BSP/NPT), Flanged (DIN PN16/ANSI), or Clamp connections available |
| Protection Class | IP65 (Standard), IP67 or IP68 (Optional) |
| Applicable Medium | Clean, low-viscosity liquids without impurities or fibers (e.g., water, alcohol, diesel, gasoline, milk) |
