What can I do with Orange Pi Zero?
Build…
A computer
A wireless server
Games
Music and sounds
HD video
A speaker
Android
Scratch
Pretty much anything else, because Orange Pi Zero is open source
Who’s it for?
Orange Pi Zero is for anyone who wants to start creating with technology – not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you.
|
Hardware specification
|
| CPU |
H2 Quad-core Cortex-A7 H.265/HEVC 1080P. |
| GPU |
·Mali400MP2 GPU @600MHz
·Supports OpenGL ES 2.0 |
| Memory (SDRAM) |
512MB DDR3 SDRAM(Share with GPU)(256MB version is Standard version) |
| Onboard Storage |
TF card (Max. 32GB)/ 2MB Spi Flash |
| Onboard Network |
10/100M Ethernet RJ45 POE is default off. |
| Onboard WIFI |
XR819, IEEE 802.11 b/g/n |
| Audio Input |
MIC |
| Video Outputs |
Supports external board via 13pins |
| Power Source |
USB OTG can supply power |
| USB 2.0 Ports |
Only One USB 2.0 HOST, one USB 2.0 OTG |
| Buttons |
Power Button |
| Low-level peripherals |
26 Pins Header,
13 Pins Header, with 2x USB, IR pin, AUDIO(MIC, AV) |
| LED |
Power led & Status led |
| Supported OS |
Android, Lubuntu, Debian |
|
Interface definition
|
| Product size |
48 mm × 46mm |
| Weight |
26g |
